Product Summary

The HCPL-2630 AVAGO is a high speed-10 MBit/s logic gate optocoupler. The HCPL-2630 AVAGO consists of a 850 nm AlGaAS LED, optically coupled to a very high speed integrated photodetector logic gate with a strobable output. This output of the HCPL-2630 AVAGO features an open collector, thereby permitting wired OR outputs. The coupled parameters are guaranteed over the temperature range of -40 to +85℃. A maximum input signal of 5 mA will provide a minimum output sink current of 13mA (fan out of 8). An internal noise shield provides superior common mode rejection of typically 10kV/μs. The applications of the HCPL-2630 A include Ground loop elimination, LSTTL to TTL, LSTTL or 5-volt CMOS, Line receiver, data transmission, Data multiplexing, Switching power supplies, Pulse transformer replacement, Computer-peripheral interface.

Parametrics

HCPL-2630 AVAGO absolute maximum ratings: (1)Supply Voltage VCC(1 minute max): 7.0 V; (2)Output Current Single channel IO: 50mA; (3)Dual channel (Each channel) 50mA; (4)Output Voltage Each channel VO: 7.0 V; (5)Collector Output Single channel PO: 85mW; (6)Power Dissipation Dual channel (Each channel): 60mW; (7)Storage Temperature TSTG: -55 to +125℃; (8)Operating Temperature TOPR: -40 to +85℃; (9)Lead Solder Temperature TSOL: 260 for 10 sec.

Features

HCPL-2630 AVAGO features: (1)Very high speed-10 MBit/s; (2)Superior CMR-10 kV/μs; (3)Double working voltage-480V; (4)Fan-out of 8 over -40 to +85℃; (5)Logic gate output; (6)Strobable output; (7)Wired OR-open collector; (8)U.L. recognized (File # E90700).

Diagrams

HCPL-2630 AVAGO block diagram
