Product Summary

The ESMM201VSN102MP50S is a high voltage, long life snap-in capacitor. It has a longer rated lifetime of 3,000 hours with the full rated ripple current applied and are also one case size smaller than equivalently rated SMH capacitors. These characteristics allow downsizing for many power supplies and will provide better reliability due to increased life. It is available in 2 or 4-pin snap-in styles and 4-pin straight terminals. And it is RoHS compliant offering Pb-free construction.

Parametrics

Absolute maximum ratings: (1)Category Temperature Range: -25 to+85℃; (2)Rated Voltage Range: 160 to 450VDC; (3)Capacitance Range: 47 to 3,300μF; (4)Capacitance Tolerance: ±20% (M) at+20℃, 120Hz.

Features

Features: (1)PC board 2 or 4-pin snap-in; optional 4-pin straight terminals; (2)Capacitance range: 47 to 3,300μF; (3)Voltage range: 160 to 450VDC; (4)Category temperature range: -25℃ to+85℃; (5)Leakage current: 3 CV (μA) maximum after 5 minutes at+20℃; (6)Standard capacitance tolerance: ±20%.

Diagrams
